Fassi Knuckle BoomMedium-Duty Cranes
From 13 t/m upwards we enter the realm of medium capacity knuckle boom cranes, which provide performance but at the same time are extremely dynamic. Suitable to be fitted on two- and three-axle trucks, in a variety of setups. The technological fittings include all the most innovative electronic, hydraulic and mechanical components. Not without reason are therefore fitted with devices that are state-of-the-art in terms of both performance and safety. To this must be added the availability of the Prolink function and a rich series of additional accessories and devices.
| Max. Lifting Capacity |  |
13,05 ton/m |
| Max. Hydraulic Outreach |  |
14,70 metre |
| Slewing Angle |  |
390° |
| Slewing Torque |  |
21,5 kNm |
| Recommended Pump Capacity |  |
40 l/min |
| Oil Tank |  |
90 litre |
| Dead Weight |  |
1640 kg |
F135A.0.21- Lifting capacity at horizontal position
| 1. | |||
| kg | 5.730 | 2.970 | 2.110 |
| m | 2,15 | 4,40 | 6,20 |
F135A.0.22 - Lifting capacity at horizontal position
| 1. | 2. | |||
| kg | 5.580 | 2.845 | 1.970 | 1.490 |
| m | 2,15 | 4,30 | 6,10 | 8,00 |
F135A.0.23 - Lifting capacity at horizontal position
| 1. | 2. | 3. | |||
| kg | 5.430 | 2.690 | 1.825 | 1.355 | 1075 |
| m | 2,15 | 4,35 | 6,15 | 8,05 | 10,05 |
F135A.0.24 - Lifting capacity at horizontal position
| 1. | 2. | 3. | 4. | |||
| kg | 5.280 | 2.690 | 1.690 | 1.225 | 945 | 775 |
| m | 2,15 | 4,35 | 6,25 | 8,15 | 10,15 | 12,20 |
F135A.0.25- Lifting capacity at horizontal position
| 1. | 2. | 3. | 4. | 5. | |||
| kg | 5.175 | 2.395 | 1.565 | 1.100 | 825 | 655 | 550 |
| m | 2,15 | 4,55 | 6,30 | 8,20 | 10,20 | 12,30 | 14,35 |
